Product |
Product id
| 953136
|
Brand
| TP-Link
|
Partnr
| VIGI C540V
|
EAN/UPC code
| 4895252500837
|
Warranty (months)
| 3 year limited warranty
|
Performance |
Type
| IP security camera
|
Placement supported
| Indoor & outdoor
|
Connectivity technology
| Wired
|
PTZ control
| Y
|
Certification
| CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
|
Design |
Mounting type
| Ceiling
|
Product colour
| White, Black
|
Housing material
| Plastic
|
International Protection (IP) code
| IP66
|
Camera |
Camera pan control
| Y
|
Camera tilt control
| Y
|
Lens viewing angle, horizontal
| 84 °
|
Lens viewing angle, vertical
| 46 °
|
Tilt angle range
| 0 - 120 °
|
Tilt speed
| 40 °/sec
|
Lens viewing angle, diagonal
| 100 °
|
Pan range
| 0 - 332 °
|
Pan speed
| 55 °/sec
|
Image sensor |
Sensor type
| CMOS
|
Number of sensors
| 1
|
Optical sensor size
| 1/3 "
|
Lens system |
Number of lenses
| 1
|
Zoom capability
| Y
|
Digital zoom
| 3 x
|
Maximum aperture number
| 1.6
|
Focal length range
| 4 - 12 mm
|
Night vision |
Night vision
| Y
|
Night vision distance
| 30 m
|
LED type
| IR
|
Number of illumination LEDs
| 1
|
Infra-red wavelength
| 850 nm
|
Video |
Maximum resolution
| 2560 x 1440 Pixels
|
Total megapixels
| 4 MP
|
Video formats supported
| H.264, H.264+, H.265, H.265+
|
Supported graphics resolutions
| 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440
|
Supported video modes
| 720p, 1080p, 1440p
|
Video recording
| Y
|
Frame rate
| 30 fps
|
Bit rate
| 256 Kbps - 4 Mbps
|
Bit rate control
| Constant Bit Rate (CBR), Variable Bit Rate (VBR)
|
Network |
Ethernet LAN
| Y
|
Wi-Fi
| N
|
Bluetooth
| N
|
Ethernet interface type
| Fast Ethernet
|
Storage |
Built-in HDD
| N
|
Card reader integrated
| Y
|
Compatible memory cards
| MicroSD (TransFlash)
|
Maximum memory card size
| 256 GB
|
Ports & interfaces |
Ethernet LAN (RJ-45) ports
| 1
|
Power |
Power source type
| PoE
|
Power consumption (typical)
| 2.9 W
|
Power consumption (max)
| 14 W
|
DC output voltage
| 12
|
Operational conditions |
Operating temperature (T-T)
| -30 - 60 °C
|
Storage temperature (T-T)
| -40 - 60 °C
|
Operating relative humidity (H-H)
| 5 - 95 procent
|
Storage relative humidity (H-H)
| 5 - 95 procent
|
Weight & dimensions |
Width
| 136 mm
|
Depth
| 139 mm
|
Height
| 107 mm
|
Weight
| 430 g
|
Package weight
| 660 g
|
Package type
| Box
|
Packaging content |
Number of cameras
| 1
|
Manual
| Y
|
