Auto Initialize for Quick Configuration
Just click “Auto Initialize” to set up basic IPC and hard disk parameters, greatly reducing your configuration time.

Specification

Product
Product id	985615
Brand	TP-Link
Partnr	VIGI NVR2016H-16MP-4TB
EAN/UPC code	4895252507195
Performance
Video input channels	16 kanalen
Video recording modes	720p, 1080p, 2160p
Supported resolutions	3840x2160, 1920x1080, 1680x1050, 1440x900, 1280x1024, 1280x720
Maximum resolution	3840 x 2160 Pixels
Video motion detection	Y
Video loss detection	Y
Multi-screen	Y
Audio formats supported	G.711, G.711 A-law, G.711 μ-law, G.726
Video formats supported	H.264, H.264+, H.265, H.265+
Input bandwidth	80 Mbit/s
Output bandwidth	60 Mbit/s
Maximum frame rate	30 fps
Wireless LAN features
Wi-Fi	N
Storage
Number of HDDs installed	1
HDD capacity	4000 GB
HDD interface	SATA
Ports & interfaces
Ethernet LAN (RJ-45) ports	16
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	16
HDMI ports quantity	1
VGA (D-Sub) output ports	1
USB 2.0 ports quantity	2
eSATA ports quantity	1
DC-in jack	Y
Features
Reset button	Y
Product colour	Black
Power
Power consumption (typical)	40 W
Power over Ethernet (PoE) power per port	30 W
Operational conditions
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	10 - 90 procent
Weight & dimensions
Width	330 mm
Depth	285 mm
Height	45 mm
Weight	2100 g
Package weight	4100 g
Packaging content
Cables included	AC
AC adapter included	Y
Quick installation guide	Y
