Product |
Product id
| 967975
|
Brand
| Viewsonic
|
Partnr
| TD2223-2
|
EAN/UPC code
| 766907008647
|
Warranty (months)
| 36 months
|
Display |
Display diagonal
| 22 inch
|
Display resolution
| 1920 x 1080 Pixels
|
Native aspect ratio
| 16:9
|
Panel type
| VA
|
Touchscreen technology
| Infrared
|
Display brightness (typical)
| 250 cd/m²
|
Response time
| 6.5 ms
|
Touch technology
| Multi-touch
|
HD type
| Full HD
|
Display technology
| LCD
|
LED backlight
| Y
|
Display surface
| Gloss
|
Screen shape
| Flat screen
|
Contrast ratio (typical)
| 3000:1
|
Contrast ratio (dynamic)
| 20000000:1
|
Maximum refresh rate
| 75 Hz
|
Viewing angle, horizontal
| 178 °
|
Viewing angle, vertical
| 178 °
|
Display number of colours
| 16.7 million colours
|
Display diagonal (metric)
| 55.9 cm
|
Pixel pitch
| 0.249 x 0.241 mm
|
Colour depth
| 8 Bit
|
sRGB coverage (typical)
| 104 procent
|
NTSC coverage (typical)
| 72 procent
|
Performance |
NVIDIA G-SYNC
| N
|
AMD FreeSync
| N
|
Flicker-free technology
| Y
|
Low Blue Light technology
| Y
|
Multimedia |
Built-in speaker(s)
| Y
|
Built-in camera
| N
|
Number of speakers
| 2
|
RMS rated power
| 4 W
|
Design |
Market positioning
| Office
|
Product colour
| Black
|
Glass thickness
| 2 mm
|
Feet colour
| Black
|
Certification
| cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, NOM, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, GEMS, VCCI, PSE, KC, K-MEPS, BIS, CCC, China RoHS, China Energy Label, CECP
|
Ports & interfaces |
Built-in USB hub
| Y
|
USB hub version
| 2.0
|
Number of USB Type-B upstream ports quantity
| 1
|
USB Type-A downstream ports quantity
| 2
|
VGA (D-Sub) ports quantity
| 1
|
DVI port
| Y
|
DVI-D ports quantity
| 1
|
HDMI
| Y
|
HDMI ports quantity
| 1
|
HDMI version
| 1.4
|
Headphone out
| Y
|
Headphone outputs
| 1
|
Headphone connectivity
| 3.5 mm
|
AC (power) in
| Y
|
Ergonomics |
VESA mounting
| Y
|
Panel mounting interface
| 100 x 100 mm
|
Cable lock slot
| Y
|
Cable lock slot type
| Kensington
|
Height adjustment
| N
|
Wall mountable
| Y
|
Tilt angle range
| 20 - 40 °
|
Tilt adjustment
| Y
|
On Screen Display (OSD)
| Y
|
Packaging data |
Stand included
| Y
|
Cables included
| AC, Audio, HDMI, USB Type-A to USB Type-B
|
Quick start guide
| Y
|
Package width
| 580 mm
|
Package depth
| 162 mm
|
Package height
| 405 mm
|
Package weight
| 5700 g
|
Power |
Power consumption (typical)
| 18.5 W
|
Power consumption (standby)
| 0.5 W
|
Power consumption (max)
| 21.8 W
|
AC input voltage
| 100 - 240 V
|
Operational conditions |
Operating temperature (T-T)
| 0 - 40 °C
|
Operating relative humidity (H-H)
| 20 - 90 procent
|
Weight & dimensions |
Width (with stand)
| 519 mm
|
Depth (with stand)
| 101 mm
|
Height (with stand)
| 329 mm
|
Weight (with stand)
| 4200 g
|
Width (without stand)
| 519 mm
|
Depth (without stand)
| 61 mm
|
Height (without stand)
| 308 mm
|
Weight (without stand)
| 3700 g
|
Other features |
Power supply type
| Internal
|
Touchscreen
| Y
|
Number of simultaneous touchpoints
| 10
|
