Designed as a companion device for the myViewBoard digital whiteboarding ecosystem, the ViewSonic myViewBoard Box instantly transforms any touch display into a digital whiteboard. That means that any interactive projector, interactive flat panel, or touch monitor, can be used as a content sharing hub for remote collaboration or distance learning. Just connect the myViewBoard Box directly to any touch display via USB-C for both video and touch control, or via HDMI and USB-A. With the built-in myViewBoard Display app for Android, and a provided security code, myViewBoard Box can mirror any myViewBoard canvas and share content from anywhere in the world.

REMOTE COLLABORATION AND DISTANCE LEARNING
With the built-in myViewBoard Display app, myViewBoard Box could mirror any myViewBoard canvas anywhere in the world. The provided security code ensures that only designated users can see and share the canvas, making the myViewBoard Box ideal for remote collaboration and distance learning.

EASY DIGITAL WHITEBOARDING
Compatible with interactive projectors, interactive flat panels, and touch monitors, the myViewBoard Box instantly transforms any touch display into a digital whiteboard. It provides an easy way to share your interactive canvas with multiple participants both locally and remotely.

SMART PODIUM FUNCTIONALITY
When combined with the ViewSonic TD2455 touch display, the myViewBoard box can turn any podium or lecturn into an interactive presentation hub. The digital canvas on the touch display can be mirrored on any projector screen or large format display. That means presenters at the front of an auditorium or classroom can manipulate content on the TD2455 touch screen, and viewers can see that content on the larger screen display.

RS232 DEVICE CONTROL
IT admin can remotely monitor, schedule, and manage the displays connected to a myViewBoard Box. With ViewSonic vController software, IT admin can turn devices on and off, change display sources, monitor device usage, etc. , for any size campus or enterprise.

WIFI AND BLUETOOTH WITH OPTIONAL DONGLE
WiFi and Bluetooth can be enabled on this device with the optional VSB050 WiFi/Bluetooth dongle. WiFi capabilities allow for screen mirroring or web browsing without connecting the LAN cable. Bluetooth provides short-range connectivity for mobile devices such as keyboards and mice, or wireless headsets.

POWER OVER ETHERNET
A single RJ45 cable can power this device and provide data at the same time.

Specification

Product
Product id	996223
Brand	Viewsonic
Partnr	VBS100-A
EAN/UPC code	766907001631
Warranty (months)	One-year limited warranty
Storage
Card reader integrated	N
Graphics
Discrete graphics adapter	N
Network
Wi-Fi	N
Ethernet LAN	Y
Ports & interfaces
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
HDMI ports quantity	2
HDMI version	1.4/2.0
Ethernet LAN (RJ-45) ports	1
Serial ports quantity	1
RS‐232/422 port	Y
DC-in jack	Y
Performance
Product colour	Black
Harmonized System (HS) code	84713000
Software
Operating system installed	Android 8.1
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90 procent
Certificates
Certification	FCC, CE, cTUVus
Weight & dimensions
Width	131.5 mm
Depth	121 mm
Height	30 mm
Weight	739 g
Package width	261 mm
Package depth	211 mm
Package height	75 mm
Package weight	940 g
Packaging content
AC adapter included	Y
Manual	Y
Cables included	HDMI
