The Neomounts by Newstar desk mount, model FPMA-D935D is a tilt-, swivel and rotatable desk mount for 2 flat screens up to 27". This mount is a great choice for space saving placement on desks using a desk clamp.

Neomounts by Newstar's versatile tilt (180°), rotate (360°) and swivel (300°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 50 centimetres. Depth adjustable from 12 to 50 centimetres. An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.

Neomounts by Newstar FPMA-D935D has three pivot points and is suitable for screens up to 27" (69 cm). The weight capacity of this product is 6 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts by Newstar VESA adapter plates.

By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.

All installation material is included with the product.

Specification

Product
Product id	234439
Brand	Neomounts
Partnr	FPMA-D935D
EAN/UPC code	8717371441715
Warranty (months)	5 year
Display
Mounting interface	VESA 75x75mm - 100x100mm
Mounting
Maximum weight capacity	6 kg
Maximum weight capacity (per display)	6 kg
Minimum screen size compatibility	14 "
Maximum screen size	27
Mounting type	Desk
Mounting	Clamp
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Panel mounting interface	75 x 75, 100 x 100 mm
Number of displays supported	2
Desk thickness (min)	30 mm
Desk thickness (max)	97 mm
Distance to the wall (min)	120 mm
Distance to the wall (max)	500 mm
Ergonomics
Height adjustment	N
Height adjustment type	Manual
Height adjustment range	0 - 500 mm
Depth adjustment range	120 - 500 mm
Tilt angle range	0 - 180 °
Swivelling	Y
Swivel angle	180 °
Angle of rotation	360 °
Cable management	Y
Rotating	Y
Tilt adjustment	Y
Remotely operated	N
Design
Product colour	Silver
Housing material	Aluminium
Weight & dimensions
Width	832 mm
Depth	514 mm
Height	500 mm
Weight	5610 g
Package width	564 mm
Package depth	230 mm
Package height	118 mm
Package weight	5300 g
Logistics data
Master (outer) case width	590 mm
Master (outer) case length	265 mm
Master (outer) case height	290 mm
Master (outer) case weight	12700 g
Quantity per master (outer) case	2 stuk(s)
Master (outer) case net weight	11900 g
Harmonized System (HS) code	HS83025000
Quantity per EUR-pallet	60 stuk(s)
Other features
Width adjustment range	0 - 832 mm
Country of origin	Taiwan
